The printing principle of this machine is to evenly transfer ink to the printing plate drum through high-precision anilox rollers, and then directly press the printing plate drum onto the surface of the belt material. After passing through the drying system, the entire printing process is completed. This machine has dozens of types of printing plate roller specifications that can be arbitrarily converted, thereby changing the printing length, accurate color matching, and a speed of up to 60 meters/minute. Can replace screen printing machines!
Online InquiryFront printing color group | 2 colors | 3colors | 4colors | 6colors |
Back color group | 1colors | 1colors | 2colors | 2colors |
Maximum printing length | 401mm | 401mm | 401mm | 401mm |
Minimum printing length | 108mm | 108mm | 108mm | 106mm |
Maximum printing width | 150mm | 150mm | 150mm | 150mm |
Maximum printing speed | 60m/min | 60m/min | 60m/min | 60m/min |
Discharge/receiving diameter | 400mm | 400mm | 400mm | 400mm |
Power supply power | 220V/5.5kw | 220V/5.5kw | 220V/5.5kw | 220V/5.5kw |
Overall weight | 560kg | 700kg | 800kg | 950kg |
Overall dimensions | 1750*700*1820mm | 2400*800*1870mm | 2400*800*1870mm | 2450*770*2150mm |
